CarbonX

Engineered Carbon for Advanced Separations

CarbonX sample extraction products are used worldwide by separation scientists to deliver unmatched purity, consistency and quality in their sample analysis. CarbonX family of carbon coated materials deliver consistent retention and capacity.The adjacent illustration shows the common characteristics of both HPLC and sample prep media. CarbonX has both of these properties which makes it a more reproducible analytical material.

CarbonX HPLC products deliver:

  • 5-10% carbon coatingvs 100% carbon thus allowing your problem compounds to elute and greater column lifetime.
  • Versatile pore size selection vs single size.
  • Selectivity for polar small molecule and therapeutic metabolites.
  • Selectivity for separations of geometric isomers.
  • Retention at high eluent temperatures.
  • Several types of CarbonX to choose from including COS and BOS.
  • Broad array of column dimensions.

CarbonX Sample Preparation products deliver:

  • Optimal selectivity for polar small molecule and therapeutic metabolites.
  • Reduced matrix effects.
  • Unsurpassed selectivity for polar compounds.
  • Consistent retention and capacity, yielding the highest SPE recovery.
  • Wide selection of sorbents.
  • Broad array of formats.

Sample Prep, HPLC, Preparative CarbonX Chemistries

CarbonX Sorbents are available in 10 different solid-phase extraction (SPE) chemistries, providing a range of options for method development.

Structure

Application

Description

HPLCPrepSample PrepGuardTrap

CarbonX COS

Water-wettable. Chemical structure of carbon covering the surface of a porous silica particle. Non endcapped. Exposed silanols. pKa ~ 5. pH Stable from 0-14 under typical SPE elution conditions.

Particle Diameter: 30-60 micron Pore Diameter: 60 Angstroms Max Pressure: 5000 psi

HPLC Particle: see specifications tab.

Extraction of acid, bases, and neutrals from aqueous or organic matrix using polarphilic, hydrophobic, and hydrogen bond interactions.

PrepSample PrepGuardTrap

CarbonX Plus

Water-wettable. Chemical structure of carbon covering the surface of a proprietary particle. Surface contains alumina endcapped with phosphate ion. pH Stable from 0-14 under typical SPE elution conditions.

Particle Diameter: 30-60 micron Pore Diameter: 60 Angstroms Max Pressure: 5000 psi

Pigment removal material. Extraction of acid, bases, and neutrals from aqueous or organic matrix using polarphilic, hydrophobic, and hydrogen bond interactions.

PrepSample PrepGuardTrap

CarbonX COF

Water-wettable. Chemical structure of carbon covering the surface of a porous magnesium silicate particle. Non endcapped. Exposed silanols. pKa ~ 5. pH Stable from 0-14 under typical SPE elution conditions.

Particle Diameter: 30-60 micron Pore Diameter: 80 Angstroms Max Pressure: 5000 psi

Extraction of polar acid, bases, and neutrals from aqueous or organic matrix using polarphilic, hydrophobic, and hydrogen bond interactions. Useful for halogenated polar compounds.

HPLCPrepSample PrepGuard

CarbonX BOS

Water-wettable. Chemical structure of bonded mixed mode fullerene on a porous silica particle. pH Stable from 0-14 under typical SPE elution conditions.

Particle Diameter: 30-60 micron Pore Diameter: 80 Angstroms Max Pressure: 5000 psi

HPLC Particle: see specifications tab.

Extraction of polar acid, bases, and neutrals from aqueous or organic matrix using anion exchange, polarphilic, hydrophobic, and hydrogen bond interactions. Less retentive than COS, COA.



PrepSample PrepGuard

CarbonX COA

Water-wettable. Chemical structure of carbon covering the surface of a porous alumina particle. Surface contains alumina endcapped with phosphate ion. pH Stable from 0-14 under typical SPE elution conditions.

Particle Diameter: 30-60 micron Pore Diameter: 60 Angstroms Max Pressure: 5000 psi

Extraction of acid, bases, and neutrals from aqueous or organic matrix using Lewis Acid, polarphilic, hydrophobic, and hydrogen bond interactions. Highly mixed mode.

CarbonX products come in a full range of device formats to meet your SPE and HPLC requirements.

96-Well Extraction Plates

  • Standard Axygen 96 well plates
  • High throughput and high recovery
  • Available in 5 mg, 10 mg, 30 mg, and 60 mg per well
  • Compatible with most liquid-handling robotic systems for automated, reliable high throughput SPE (HT-SPE)

SPE Cartridges

  • Ultra-clean syringe barrel and frits
  • Available in cartridges ranging from 1 cc to 60 cc
  • Also available in 150 mL cartridges with Luer inlet hub and outlet tip with 150 mg sorbent

FEP Cartridges

  • Ultra-clean glass syringe with Teflon® frit
  • For trace level detection and analysis at part-per-trillion (PPT) levels
  • Available in 5 cc (200 mg) configuration

On-Line Columns and Cartridges

  • For rugged, reproducible, and ultra-fast on-line analysis
  • Wide choice of configurations, particle sizes, and sorbent chemistries
  • Available with CarbonX and CarbonX PLB sorbents—COA, COA, BOS, COF, PLB, PCX, PAX, PCX, and PWAX
  • High recovery and reproducible results for a wide range of compounds.

HPLC Columns

  • Ideal for retenion of polar molecules in reverse or normal phase.
  • Selective for geometric isomers.

Elution Spin Columns

  • No evaporation and reconstitution necessary due to elution volumes as low as 25 µL
  • Ideal for SPE cleanup and analyte enrichment of small sample volumes
  • Up to a 15x increase in concentration
  • Compatible with most liquid-handling robotic systems for automated, reliable high throughput SPE (HT-SPE)

Dual and Tri Phase SPE Cartridges

  • Configure your SPE with up to 3 sorbents
  • Ultra-clean syringe barrel and frits
  • Available in cartridges ranging from 1 cc to 60 cc
  • Also available in 150 mL cartridges with Luer inlet hub and outlet tip with 150 mg sorbent.
  • You've just added this product to the cart:

    UNIVERSAL dSPE Tubes for All Matrices

    0 out of 5

    UNIVERSAL dSPE Tubes for All Matrices

    This is dSPE tube is configured with both CarbonX and LipidX for high lipid matrices for multi-residue analysis. These UNIVERSAL dSPE tubes are configured with CarbonX, LipidX, C18, magnesium sulphate; and PSA (primary-secondary amine SPE sorbent). Since CarbonX and LipidX removes matrix and does not remove the pesticides, we recommend these unique sorbents as a logical addition to all QuEChERS tubes for all matrices- even for non pigmented samples. The kit consists of 2 mL (100 units) or 15 mL (50 units) centrifuge tubes.

    $135.00$160.00
  • You've just added this product to the cart:

    EN 15662 dSPE Tube

    0 out of 5

    EN 15662 dSPE Tube

    This is dSPE tube is configured to meet the requirements of EN 15662 QUECHERS methods used for multi-pesticide residue analyses in food.

    $120.00$130.00
  • You've just added this product to the cart:

    AOAC dsPE Tubes

    0 out of 5

    AOAC dsPE Tubes

    This is dSPE tube is configured to meet the requirements of AOAC 2007:01 QUECHERS methods used for multi-pesticide residue analyses in food. The kit consists of 2 mL (100 units) or 15 mL (50 units) centrifuge tubes optionally containing magnesium sulphate; PSA (primary-secondary amine SPE sorbent); alumina; CarbonX or C18. See table below for details.

    $120.00$160.00
  • You've just added this product to the cart:

    CarbonX SPE Tubes

    0 out of 5

    CarbonX SPE Tubes

    CarbonX brand carbon for SPE and dSPE applications.
    CarbonX COS: 32-63 µm, 60 angstrom pore, 10% carbon, silanols present
    CarbonX COA: 32-63 µm, 80 angstrom pore, 10% carbon, lewis acid sites present
    CarbonX Plus for QuEChERS: 32-63 µm, 80 angstrom pore, 5% carbon

    $155.00$170.00
  • You've just added this product to the cart:

    Tri Phase SPE Tube

    0 out of 5

    Tri Phase SPE Tube

    Tri Phase SPE containing 500 mg PSA/500 mg CarbonX +/500mg LipidX. 6mL cartridges only. Sold in packs of 30. Tri phase SPE cartridge does what you want it to do: Sorbs lipid rich matrix and not pesticides. This configuration has shown a high recovery of planar species without the use of toluene.

    $225.00
  • You've just added this product to the cart:

    CarbonX Plus - Carbon for QuEChERS

    0 out of 5

    CarbonX Plus – Carbon for QuEChERS

    CarbonX brand QuEChERS, SPE, and dSPE Additives

    This is the carbon with super high performance for QuEChERS! High Matrix removal. High Planar Pesticide Recovery.

    CarbonX products are based on carbon coated porous substrates.

    • Substitute for GCB w/w
    • Inert Substrate
    • Just Enough Carbon
    • 80 angstrom pore diameter
    • 32-63 micron particle size
    $300.00$500.00
